Technical Data
Free Sample
Please ask for free sample in order to check if the products meets your requirement for your application.
Send your delivery adress and your specific requirements.
Description
- Prismatic ultra-thin supercapacitors
- Single or double cell version
- Ultra-compact design
- High pulse power
Unique Selling Proposition
- Excellent low temperature performance
- High power density
- Low ESR with high current handling
- Very low self discharge
Applications
- Sensors
- Small mobile devices
- Small power supplies
- Mobile energy harvesting
- Uninterruptible power supply
Rated Voltage
2.5 / 5 V
Capacity
90 - 2400 mF
Allowable Operation Temperature
-40 °C to 70 °C
RMS current
4.5 - 8 A
Peak Current
30 A
Mounting
PCB,SMT
Soldering Methods
Manual
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about Approvals
SCHURTER products are designed for use in industrial environments. They have approvals from independent testing bodies according to national and international standards. Products with specific characteristics and requirements such as required in the automotive sector according to IATF 16949, medical technology according to ISO 13485 or in the aerospace industry can be offered exclusively with customer-specific, individual agreements by SCHURTER.
Compliances
The product complies with following Guide Lines
| Identification | Details | Initiator | Description |
|---|---|---|---|
|
SCHURTER AG | The CE marking declares that the product complies with the applicable requirements laid down in the harmonisation of Community legislation on its affixing in accordance with EU Regulation 765/2008. | |
|
SCHURTER AG | The UKCA marking declares that the product complies with the applicable requirements laid down in the British Amendment of Regulation (EC) 765/2008. | |
|
SCHURTER AG | Directive RoHS 2011/65/EU, Amendment (EU) 2015/863 | |
|
SCHURTER AG | The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March 2007. It is similar to the EU directive RoHS. | |
|
SCHURTER AG | On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration, Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as "REACH") entered into force. |
LOADING...
Short Table of Variants SCPB Open complete table SCPB
| Cell Type | Rated Voltage [V] | Capacity [mF] |
Order Number
|
Free Sample |
Distributor Stock Check Distributor Stock Check
|
... | |
|---|---|---|---|---|---|---|---|
| Low ESR Single Cell | 2.5 | 170 | 3-153-413 | - | ... | ||
| Low ESR Single Cell | 2.5 | 180 | 3-153-414 | - | ... | ||
| Low ESR Single Cell | 2.5 | 320 | 3-153-415 | - | ... | ||
| Low ESR Single Cell | 2.5 | 540 | 3-153-416 | - | ... | ||
| Low ESR Single Cell | 2.5 | 800 | 3-153-417 | - | ... | ||
| Low ESR Single Cell | 2.5 | 800 | 3-153-418 | - | ... | ||
| Low ESR Single Cell | 2.5 | 1040 | 3-153-419 | - | ... | ||
| Low ESR Single Cell | 2.5 | 1360 | 3-153-420 | - | ... | ||
| Low ESR Single Cell | 2.5 | 1800 | 3-153-421 | - | ... | ||
| Low ESR Single Cell | 2.5 | 2400 | 3-153-422 | - | ... | ||
| Low ESR Dual Cell | 5 | 90 | 3-153-423 | - | ... | ||
| Low ESR Dual Cell | 5 | 90 | 3-153-424 | - | ... | ||
| Low ESR Dual Cell | 5 | 160 | 3-153-425 | - | ... | ||
| Low ESR Dual Cell | 5 | 270 | 3-153-426 | - | ... | ||
| Low ESR Dual Cell | 5 | 400 | 3-153-427 | - | ... | ||
| Low ESR Dual Cell | 5 | 400 | 3-153-428 | - | ... | ||
| Low ESR Dual Cell | 5 | 520 | 3-153-429 | - | ... | ||
| Low ESR Dual Cell | 5 | 680 | 3-153-430 | - | ... | ||
| Low ESR Dual Cell | 5 | 900 | 3-153-431 | - | ... | ||
| Low ESR Dual Cell | 5 | 1200 | 3-153-432 | - | ... |
| Packaging Unit | 100 Pcs |
